MOTIV Reflex + with B58/S58/N54/N55/S55 Flying lead harness
Included is the Reflex+ with BMW/ Supra A9X Flying lead harness.
The ReFlex+ is an advanced integration module that allows control of auxiliary components through a variety of control strategies.
Standalone - no CanBUS communication
Integrated CanBUS - MHD, BM3, MGF
Advanced CanBUS - EcuTek and MHD+
he ReFlex+ has the ability to integrate or control:
Sequential port injection control for up to eight injectors
4x Auxiliary Inputs (Flex Fuel Analyzer, 2x 4-20mA pressure sensors, and 1x 0-5v sensor)
4x Auxiliary Outputs (Ground / Low Side Triggers)
1x CanBUS communication
1x Crank Sensor Input
1x Cam Sensor Input
1x MAP Sensor Input
The additional outputs of the ReFlex+ allow you to control aftermarket performance parts such as:
Methanol Injection Kits
Nitrous Kits
Boost Control Solenoids
Fuel Pumps
Relay Triggers
Line Locks
Inputs
1 Digital 0-500kHz for Ethanol (output over CanBUS)
1 Digital 0-20kHz for Crank Signal
1 Digital 0-20kHz for Cam Signal
1 Analog 0-5v ~6Hz Low-Pass MAP Sensor
1 Analog 0-5v ~6Hz Low-Pass Sensor
1 Analog 4-20mA current ~30Hz Low-Pass Fuel Pressure
1 Analog 4-20mA current ~30Hz Low-Pass Pressure Sensor
Outputs
2 Low-Side, 0-1000Hz, 4A cont, 8A max`
2 Low-Side, 0-1000Hz, 3A cont, 6A max
1 Digital to Analog Expansion
CanBUS Lo/High Comms
Useful Links
Tuner Pro RT (Please consider donating to them)
READ BEFORE UPDATING FIRMWARE!
ADX File for live gauges in Tuner Pro
Tuning Files (Starter Maps-Bins & XDFs)
”To run MHD+ PI control you must first update to 6.2 or newer firmware then flash the .bin file for your vehicle engine version. That is it! Do not apply any patches for canbus, tmap options, etc. The ONLY active feature internal is you can select the hz output for each aux if you wish to change it for different components. Current Supported Models -BMW B58 Gen2 Bench unlock -BMW S58 Bench unlock -BMW B58 Gen 2 FEMTO unlock -BMW S58 FEMTO unlock”
